The Zimmermann Formula Z brake disc is designed with the aim of simple installation paired with optimum braking under high mechanical and thermal load.  The compound developed by Zimmermann accommodates the increased demands incurred by engine tuning and optimised chassis structures.

Advantages:

  • Excellent deceleration action and no distortion of friction ring at high temperatures
  • Substantial weight saving and therefore less unsprung mass
  • Floating mounting enables radial expansion of the brake disc under relatively heavy loads, thus preventing shielding and increasing resistance to heat cracks
  • Hot spots" prevented by optimised design of ventilation channels
  • 1:1 exchange of original disc possible
  • Not subject to registration: general ABE certification supplied with disc
  • No conversion required for brake tuning

Technical Information:

Fitting Position : Rear Axle Left
paired article number : 100.3346.75
Height [mm] : 48 mm
Outer Diameter [mm] : 335 mm
Weight [kg] : 6.9 kg
Brake Disc Type : Vented
Brake Disc Type : two-piece brake disc
Brake Disc Type : floating brake disc
Brake Disc Type : Aluminium Brake Disc Hub
Brake Disc Thickness [mm] : 22 mm
Minimum Thickness [mm] : 20.4 mm
Surface : Coated
Hole Arrangement/Number : 10/5
Pitch Circle Ø [mm] : 112 mm
Centering Diameter [mm] : 68 mm
Finish : Alloyed/High-carbon
Rim Hole Number : 5 -Hole

SKU 100.3345.75_X2
Brand Zimmermann
Fitting Position Rear Axle Left
paired article number 100.3346.75
Height [mm] 48 mm
Outer Diameter [mm] 335 mm
Weight [kg] 6.9 kg
Brake Disc Type Vented
Brake Disc Type two-piece brake disc
Brake Disc Type floating brake disc
Brake Disc Type Aluminium Brake Disc Hub
Brake Disc Thickness [mm] 22 mm
Minimum Thickness [mm] 20.4 mm
Surface Coated
Hole Arrangement/Number 10/5
Pitch Circle Ø [mm] 112 mm
Centering Diameter [mm] 68 mm
Finish Alloyed/High-carbon
Rim Hole Number 5 -Hole
